John Deere Lvu17015 Retaining Pin – Oem Fastener For Precision Assemblies

Description

John Deere Original Equipment Pin – LVU17015

Part Specifications:
Diameter (IN) 0.3740
Length (IN) 2.5197
Eye Diameter (IN) 0.2720
Head Diameter (IN) 0.5512
Hole Diameter (IN) 0.1272
End to Hole (IN) 0.8465
See Sketch (IN) 0.2000
Material (ALPHA) 1038CD
Finish (ALPHA) B-Zinc-Electro Plated

Fits the following John Deere models:
Compact Utility Tractor: 1023E, 54D, 60D, 3039R, 3046R, 1025R, 260, 1026R, 2025R, 2026R, 2027R, 2032R, 3033R, 3038R, 3039R, 3045R, 3046R, 3120, 3320, 3520, 3720.
Tractor: 1023E, 2032R, 2038R, 2032R, 2038R, 3039R.
Lawn And Garden Tractor: X734, X738, X739, X750, X754, X758.

This is an O.E.M. John Deere part.
